Process Equipment

heading-hr1
Gas Coolers

Gas Coolers

heading-hr

Application:

  • Intercoolers and Aftercoolers for Centrifugal Compressors

Specifications:

  • Plain tube and Plate-fin type
  • Up to 300,000kg/h flows
  • Pressure Drop up to 30mBar
  • Conforming to TEMA RCB, ASME, AD Merkblatter, EN13445
  • Materials: Copper alloy, Nickel Alloy, SS304L, SS316L, SS904L, Titanium, Super Duplex

Shell & Tube Heat Exchangers

heading-hr

Application:

  • Applications: ZLD / Desalination / Chemical / Food / Oil & Gas / Power / Pharmaceutical

Specifications:

  • Optimally designed for high performance and long life using PVElite, NozzlePro and HTRI
  • Conforming to TEMA RCB
  • Material : Stainless Steel, Carbon Steel, Admirality Brass, Duplex, Cupro Nickel, Titanium Grade 2, Super Duplex Stainless Steel
Shell & Tube Heat Exchangers
Pressure Vessels

Pressure Vessels

heading-hr

Application:

  • For normal as well as hazardous application

Specifications:

  • Optimally designed for high performance and long life using PVElite and NozzlePro software
  • Diameter: Up to 4m
  • Length: Up to 50m
  • Weight: Up to 100Ton
  • Thickness: Up to 100mm
  • Materials: Incoloy 825, Super Duplex and Super Austenitic Stainless Steel, SS316, SS304, Carbon Steel

Crystallizers

heading-hr

Application:

  • Applications: Zero Liquid Discharge and Chemicals

Specifications:

  • MOC: Super Duplex and Super Austenitic Stainless Steel
Process Equipment
Condensers

Condensers

heading-hr

Application:

  • For Power applications
  • MOC:

Specifications:

  • Tubes: Admirality Brass, Titanium, Super Duplex, Super Austenitic Stainless Steel
  • Shell: Carbon Steel

Air Coolers

heading-hr

Application:

  • For lube oil cooling, inter-cooling, after-cooling on compressors and other process applications

Specifications:

  • Manufactured and tested per API 661 standard and ASME ‘U’ Stamp
  • Capacity: Up to 5000kW
Air Coolers
Volume Bottles

Volume Bottles

heading-hr

Application:

  • For reciprocating compressors

Specifications:

  • MOC: Carbon Steel and Stainless Steel
